Specifications
| 1D Code types | Auto discriminates all standard 1D codes |
|---|---|
| 2D Code Types | Aztec Code, Data Matrix, MaxiCode, QR Code |
| Approvals | RoHS |
| Color | Black / black |
| Dimension (mm) | 60 x 75 x 84 |
| Drop resistance | Withstands repeated drops from 1.2 m / 4 ft onto a concrete surface |
| Humidity | 5 - 95% (Non-condensing) |
| Immunity To Ambient Light | 0 - 86,100 lux |
| Interface | USB; RS-232 |
| IP Class | IP52 |
| Output current | <500 mA |
| Postal Code Types | China Post, IMB, KIX Post, Planet Code, Postnet, Royal Mail Code (RM4SCC), Portuguese Post, Swedish Post, Australia Postal, Japan Postal, Canadian Post |
|---|---|
| Readable code types | 1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes, Digital Watermarking |
| Reading Angle Window | Pitch:+/-65°; Tilt: +/- 0-360°; Skew: +/-75° |
| Resolution | 0.130 mm / 5 mils |
| Stacked Code Types | GS1 Databar Composites, GS1 Databar Expanded Stacked, GS1 Databar Stacked, GS1 Databar Stacked Omnidirectional, Micro PDF 417, PDF 417 |
| Temperature range bearing, from | -40 |
| Temperature range bearing, to | 70 |
| Temperature range from | 0 |
| Temperature range to | 40 |
| Weight | 170 |
