Datalogic Gryphon™ I GD4500

The Gryphon GD4500 product series from Datalogic represents the premium level of hand held scanners for general purpose applications. The dedicated optics specifically designed and uniquely tailored for the Gryphon, exploit a megapixel sensor and distinctive technology with highly visible warm-white illumination to achieve outstanding omnidirectional reading performance. Because of the increased motion tolerance, codes placed on fast-moving objects can be easily and quickly captured, creating the ideal hand held scanner for tasks requiring high throughput.

Whether in department or specialty stores, in hyper stores and supermarkets, convenience stores or groceries, the Gryphon GD4500 scanner fits most any retail in-store requirement for POS checkout.



A specialized model with red illumination provides the ultimate Digimarc® Barcode reading, as Digital Watermarking has become a new reality for top retailers.

In the dedicated models with Disinfectant-Ready and Anti-Microbial enclosures, the Gryphon I GD4500 scanner is the ideal companion for Healthcare applications such as in laboratories and bedside point-of-care.



  • Detects 1D/2D code types
  • Image sensor: 1MP, 1280 x 800 pixels
  • Disinfectant ready enclosures
  • Interfaces: USB type C, USB, RS-232, multi interface

Selected variant

Avaible in several variants

Selected variant

Specifications

1D Code types Auto discriminates all standard 1D codes
2D Code Types Aztec Code, China Han Xin Code, Data Matrix, MaxiCode, Micro QR Code, QR Code, Dot Code
Approvals RoHS
Color Black
Dimension (mm) 166 x 68 x 109
Drop resistance Withstands repeated drops from 6ft on concrete surface
Humidity 0-95% (Non-condensing)
Immunity To Ambient Light 0 - 100,000 lux
Interface USB type C / USB only
IP Class IP52
Kit No
Light Source Warm white
Output current <400mA @ 5V, <200mA @ 12V
Postal Code Types China Post, IMB, KIX Post, Planet Code, Postnet, Royal Mail Code (RM4SCC), UK Postal, Australia Postal, Japan Postal
Readable code types 1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
Reading Angle Window Pitch:+/-65°; Tilt: 360°; Skew: +/-65°
Resolution 0.102 mm / 4mils
Sensor type 1 Megapixel: 1280 x 800 pixels
Stacked Code Types EAN/JAN Composites, GS1 Databar Composites, GS1 Databar Expanded Stacked, GS1 Databar Stacked, GS1 Databar Stacked Omnidirectional, Macro PDF, Micro PDF 417, PDF 417, UPC A/E Composites
Temperature range bearing, from -40
Temperature range bearing, to 70
Temperature range from 0
Temperature range to 50
Weight 161
Wireless No

Product description

The Gryphon GD4500 product series from Datalogic represents the premium level of hand held scanners for general purpose applications. The dedicated optics specifically designed and uniquely tailored for the Gryphon, exploit a megapixel sensor and distinctive technology with highly visible warm-white illumination to achieve outstanding omnidirectional reading performance. Because of the increased motion tolerance, codes placed on fast-moving objects can be easily and quickly captured, creating the ideal hand held scanner for tasks requiring high throughput.

Whether in department or specialty stores, in hyper stores and supermarkets, convenience stores or groceries, the Gryphon GD4500 scanner fits most any retail in-store requirement for POS checkout.



A specialized model with red illumination provides the ultimate Digimarc® Barcode reading, as Digital Watermarking has become a new reality for top retailers.

In the dedicated models with Disinfectant-Ready and Anti-Microbial enclosures, the Gryphon I GD4500 scanner is the ideal companion for Healthcare applications such as in laboratories and bedside point-of-care.



Accessories

Related products

My favourites Articles Color Extra Features Interface Kit Light Source Readable code types Resolution Price
Black
USB type C / USB only
No
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.102 mm / 4mils
Black
Kit includes: Scanner and All in One Permanent Base
USB type C / USB only
Yes
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.102 mm / 4mils
Black
Kit includes: Scanner and USB Cable 90A052258
USB type C / USB only
Yes
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.102 mm / 4mils
Black
Kit includes: Scanner, All in One Permanent Base and USB Cable 90A052258
USB type C / USB only
Yes
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.102 mm / 4mils
Black
Kit includes: Scanner, USB Cable 90A052258 and Stand
USB type C / USB only
Yes
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.102 mm / 4mils
White
Kit includes: Scanner and USB Cable 90A052278
USB type C / USB only
Yes
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.102 mm / 4mils
White
Kit includes: Scanner and USB Cable 90A052278
USB type C / USB only
Yes
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.077 mm / 3 mils
Black
USB type C, USB, RS-232, Keyboard wedge multi interface
No
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.102 mm / 4mils
Black
Kit includes: Scanner and All in One Permanent Base
USB type C, USB, RS-232, Keyboard wedge multi interface
Yes
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.102 mm / 4mils
Black
USB type C, USB, RS-232, Keyboard wedge multi interface
No
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.077 mm / 3 mils
Black
USB type C, USB, RS-232, Keyboard wedge multi interface
No
Hyper red
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes, Digital Watermarking
0.102 mm / 4mils
White
USB type C, USB, RS-232, Keyboard wedge multi interface
No
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.102 mm / 4mils
White
Kit includes: Scanner and USB Cable 90A052278
USB type C, USB, RS-232, Keyboard wedge multi interface
Yes
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.102 mm / 4mils
White
Kit includes: Scanner and USB Cable 90A052278
USB type C, USB, RS-232, Keyboard wedge multi interface
Yes
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.077 mm / 3 mils
Black
Kit includes: Scanner and USB Cable 90A052258
USB type C / USB only
Yes
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.102 mm / 4mils
Black
Kit includes: Scanner and USB Cable 90A052258
USB type C / USB only
Yes
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.102 mm / 4mils
Black
Kit includes: Scanner and USB Cable 90A052258
USB type C / USB only
Yes
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.077 mm / 3 mils
Black
Kit includes: Scanner and All in One Permanent Base
USB type C, USB, RS-232, Keyboard wedge multi interface
Yes
Warm white
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.077 mm / 3 mils
White
Kit includes: Scanner and USB Cable 90A052278
USB type C, USB, RS-232, Keyboard wedge multi interface
Yes
Hyper Red
1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes
0.077 mm / 3 mils
