Coil Material | Epoxy |
---|---|
Connection Thread | 1/8 BSP |
Differential Pressure Air Max | 8 |
Differential Pressure Min | 0 |
Differential Pressure Oil Max | 5 |
Differential pressure vacuum max | 1 |
Differential Pressure Water Max | 5 |
Flow Factor / Flow Coefficient | 0,05 |
Flow Max l/min Double | 0,7 |
Function 1 | 2/2 |
Function 2 | Normally Closed (SPST) |
IP Class | IP65 |
Material Body | Brass |
Material Plunger | Stainless steel |
Material Slide Ring | PTFE |
Materials Seat | Brass |
---|---|
Materials Seat Seal | FPM |
Materials Spring | Stainless steel |
Max. pressure | 35 |
Power Consumption | 6,3 |
Sensitivity | <1% |
Temperature range from | 0 |
Temperature range of media from | 0 |
Temperature range of media to | 50 |
Temperature range to | 40 |
Throughput | 1,2 |
Weight | 0,2 |
Viscosity Max | 50 |
Voltage DC | 24 |
|
|
|
|
|
||
---|---|---|---|---|---|---|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
My favourites | Articles | Differential Pressure Air Max | Differential Pressure Oil Max | Differential Pressure Water Max | Flow Factor / Flow Coefficient | Flow Max l/min Double | Material Body | Materials Seat | Throughput | Price | |
---|---|---|---|---|---|---|---|---|---|---|---|
![]()
Proportional valve 2/2 NC 1/8" 24VDC
Art:
SCG202A201VS3
Copied
|
8
|
5
|
5
|
0,05
|
0,7
|
Brass
|
Brass
|
1,2
|
| ||
![]()
Proportional valve 2/2 NC 1/8" 24VDC
Art:
SCG202A202VS3
Copied
|
8
|
4
|
4
|
0,07
|
1,1
|
Brass
|
Brass
|
1,6
|
| ||
![]()
Proportional valve 2/2 NC 1/8" 24VDC
Art:
SCG202A203VS3
Copied
|
4
|
3
|
3
|
0,13
|
2,2
|
Brass
|
Brass
|
2,4
|
| ||
![]()
Proportional valve 2/2 NC 1/8" 24VDC
Art:
SCG202A204VS3
Copied
|
2,5
|
2,5
|
2,5
|
0,18
|
2,9
|
Brass
|
Brass
|
3,2
|
| ||
![]()
Proportional valve 2/2 NC 1/8" 24VDC
Art:
SCG202A205VS3
Copied
|
8
|
5
|
5
|
0,05
|
0,7
|
Stainless steel 303
|
Brass
|
1,2
|
| ||
![]()
Proportional valve 2/2 NC 1/8" 24VDC
Art:
SCG202A206VS3
Copied
|
8
|
4
|
4
|
0,07
|
1,1
|
Stainless steel 303
|
Stainless steel
|
1,6
|
| ||
![]()
Proportional valve 2/2 NC 1/8" 24VDC
Art:
SCG202A207VS3
Copied
|
4
|
3
|
3
|
0,13
|
2,2
|
Stainless steel 303
|
Stainless steel
|
2,4
|
| ||
![]()
Proportional valve 2/2 NC 1/8" 24VDC
Art:
SCG202A208VS3
Copied
|
2,5
|
2,5
|
2,5
|
0,18
|
2,9
|
Stainless steel 303
|
Stainless steel
|
3,2
|
|
Select a variant in the list
