Valco - Side Mount Level Switch- ML Series 00.0002.5675

Current

0.5AC/0.7DC

Electrical connection

Pre-cabled 1.5m

Function

N/O & N/C

Manufacturer Part No

S1.PML.3D.GC-.Z.C1

Material of seals

FKM

Materials Wetted Parts

Polypropylene

Max. pressure

Mounting

Horizontal

Specific gravity

0.6

Temperature range to

Voltage

300AC/350DC

Articles	Electrical connection	Manufacturer Part No	Materials Wetted Parts	Max. pressure	Specific gravity	Temperature range to
53mm length, Polypropylene, NC/NO, 1.5M cable, Max 3 bar Art: 00.0002.5675 Copied	Pre-cabled 1.5m	S1.PML.3D.GC-.Z.C1	Polypropylene	3	0.6	90
53mm length, Polypropylene, NC/NO, 3M cable, Max 3 bar Art: 00.0002.8284 Copied	Pre-cabled 3m	S1.PML.3D.GC-.Z.C2	Polypropylene	3	0.6	90
53mm length, Polypropylene, NC/NO, 5M cable, Max 3 bar Art: 00.0002.7665 Copied	Pre-cabled 5m	S1.PML.3D.GC-.Z.C5M	Polypropylene	3	0.6	90
53mm length, Polypropylene, NC/NO, 10M cable, Max 3 bar Art: 00.0002.9100 Copied	Pre-cabled 10m	S1.PML.3D.GC-.Z.C10M	Polypropylene	3	0.6	90
53mm length, PVDF, NC/NO, 1.5M cable, Max 6 bar Art: 00.0002.8790 Copied	Pre-cabled 1.5m	S1.FML.3D.GC-.Z.C1	PVDF	6	0.75	130
53mm length, PVDF, NC/NO, 3M cable, Max 6 bar Art: 00.0002.5910 Copied	Pre-cabled 3m	S1.FML.3D.GC-.Z.C2	PVDF	6	0.75	130
53mm length, PVDF, NC/NO, 5M cable, Max 6 bar Art: 00.0002.7719 Copied	Pre-cabled 5m	S1.FML.3D.GC-.Z.C5M	PVDF	6	0.75	130
53mm length, PVDF, NC/NO, 10M cable, Max 6 bar Art: 00.0002.9119 Copied	Pre-cabled 10m	S1.FML.3D.GC-.Z.C10M	PVDF	6	0.75	130

Select a variant in the list

Valco - Side Mount Level Switch- ML Series
