The SL conductive probe series provides a solution for controlling the level of liquid with a minimum value of conductivity of 1µs.
The probes are available in a wide variety of materials and process connections and are of construction appropriate to operation in extreme conditions such as those found on industrial plants.
Electrical connection | DIN A 43650 |
---|---|
Electrode Length | 500mm |
IP Class | IP65 |
Manufacturer Part No | SLP.25G.3X500.K.S1 |
Material of coatings on electrodes | PVDF |
Material of connection | Polypropylene |
Max. pressure | 6 |
Mounting | Vertical |
Number of electrodes | 3 |
Process connection | G1 |
Temperature range to | 100 |
The SL conductive probe series provides a solution for controlling the level of liquid with a minimum value of conductivity of 1µs.
The probes are available in a wide variety of materials and process connections and are of construction appropriate to operation in extreme conditions such as those found on industrial plants.
|
|
|
|
|
||
---|---|---|---|---|---|---|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
My favourites | Articles | Electrode Length | Manufacturer Part No | Number of electrodes | Process connection | Price | |
---|---|---|---|---|---|---|---|
![]()
500mm length, 3xelectrodes, G1
Art:
00.0008.0053
Copied
|
500mm
|
SLP.25G.3X500.K.S1
|
3
|
G1
|
| ||
![]()
500mm length, 2xelectrodes, G1/2
Art:
00.0008.0054
Copied
|
500mm
|
SLP.15G.2X500.K.S1
|
2
|
G1/2
|
| ||
![]()
Art:
00.0008.0055
Copied
|
500mm
|
SLP.40G.4X500.K.S1
|
4
|
G1 1/2
|
| ||
![]()
Art:
00.0008.0057
Copied
|
1000mm
|
SLP.40G.4X1000.K.S1
|
4
|
G1 1/2
|
| ||
![]()
1000mm length, 3xelectrodes, G1
Art:
00.0008.0059
Copied
|
1000mm
|
SLP.25G.3X1000.K.S1
|
3
|
G1
|
| ||
![]()
1000mm length, 2xelectrodes, G1/2
Art:
00.0008.0087
Copied
|
1000mm
|
SLP.15G.2X1000.K.S1
|
2
|
G1/2
|
| ||
![]()
500mm length, 1xelectrode, G3/8
Art:
00.0008.0098
Copied
|
500mm
|
SLP.10G.1X500.K.S1
|
1
|
G3/8
|
| ||
![]()
1000mm length, 1xelectrode, G3/8
Art:
00.0008.0115
Copied
|
1000mm
|
SLP.10G.1X1000.K.S1
|
1
|
G3/8
|
| ||
![]()
2000mm length, 1xelectrode, G3/8
Art:
00.0008.0188
Copied
|
2000mm
|
SLP.10G.1X2000.K.S1
|
1
|
G3/8
|
| ||
![]()
500mm length, 1xelectrode, G1/2
Art:
00.0008.0101
Copied
|
500mm
|
SLP.15G.1X500.K.S1
|
1
|
G1/2
|
| ||
![]()
1000mm length, 1xelectrode, G1/2
Art:
00.0008.0189
Copied
|
1000mm
|
SLP.15G.1X1000.K.S1
|
1
|
G1/2
|
| ||
![]()
1500mm length, 1xelectrode, G1/2
Art:
00.0008.0138
Copied
|
1500mm
|
SLP.15G.1X1500.K.S1
|
1
|
G1/2
|
| ||
![]()
2000mm length, 1xelectrode, G1/2
Art:
00.0008.0190
Copied
|
2000mm
|
SLP.15G.1X2000.K.S1
|
1
|
G1/2
|
| ||
![]()
1500mm length, 1xelectrode, G3/8
Art:
00.0008.0187
Copied
|
1500mm
|
SLP.10G.1X1500.K.S1
|
1
|
G3/8
|
| ||
![]()
1500mm length, 2xelectrodes, G1/2
Art:
00.0008.0135
Copied
|
1500mm
|
SLP.15G.2X1500.K.S1
|
2
|
G1/2
|
| ||
![]()
2000mm length, 2xelectrodes, G1/2
Art:
00.0008.0191
Copied
|
2000mm
|
SLP.15G.2X2000.K.S1
|
2
|
G1/2
|
| ||
![]()
1500mm length, 3xelectrodes, G1
Art:
00.0008.0100
Copied
|
1500mm
|
SLP.25G.3X1500.K.S1
|
3
|
G1
|
| ||
![]()
2000mm length, 3xelectrodes, G1
Art:
00.0008.0140
Copied
|
2000mm
|
SLP.25G.3X2000.K.S1
|
3
|
G1
|
| ||
![]()
Art:
00.0008.0137
Copied
|
1500mm
|
SLP.40G.4X1500.K.S1
|
4
|
G1 1/2
|
| ||
![]()
Art:
00.0008.0130
Copied
|
2000mm
|
SLP.40G.4X2000.K.S1
|
4
|
G1 1/2
|
|
Select a variant in the list
