Model CRG is a universal flow switch in brass or stainless steel. The same switch can be used for a large number of different pipe dimensions by using one or more paddle lengths. Four different paddle lengths are included.
Connection | External thread 1 " |
---|---|
Contact Rating Max | 15 |
Deviation max | ±15 % |
Electrical Connection | PG11 |
Flow Range Max | 165,7 |
Flow Range Min | 0,6 |
Function | Paddle, micro switch switching |
Hysteresis | Depending on the breaking value, however, at least 0.1 l / min |
IP Class | IP65 |
Material Base | Zinc-plated steel |
Material of connection | Brass |
Materials Bellows | Tombak |
Materials Cover | ABS plastic |
Materials Paddle | Stainless steel 316Ti |
---|---|
Media | Water, (oil on request) |
Pipe dimension max | 200 |
Pipe dimension min | 25 |
Pressure drop | Approx. 0.08 bar at max. flow |
Pressure Range Max | 11 |
Temperature range of media to | 120 |
Type of flow component | Flow Switches |
Weight | 0,95 |
Viscosity | 1 |
Voltage AC max | 250 |
Model CRG is a universal flow switch in brass or stainless steel. The same switch can be used for a large number of different pipe dimensions by using one or more paddle lengths. Four different paddle lengths are included.
|
|
|
|
|
||
---|---|---|---|---|---|---|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
My favourites | Articles | Material of connection | Materials Bellows | Media | Weight | Price | |
---|---|---|---|---|---|---|---|
![]()
Art:
CRG-025HMS
Copied
|
Brass
|
Tombak
|
Water, (oil on request)
|
0,95
|
| ||
![]()
Art:
CRG-025HKS
Copied
|
Stainless steel 316Ti
|
Stainless steel 316Ti
|
Water, aggressive media (oil on request)
|
1,15
|
|
Select a variant in the list
