Honsberg - WR1 series Flow Indicator
Sight glass/rotor
The WR1 mechanical flow indicator is designed for use with water, oils and air/gases to show a quantitative flow display though a spinning rotor.
- Ranges covering 0.7..100 l/min H2O
- Ranges covering18 to 700 l/min air (1 bar)
- 16 bar max
- Brass connections
Selected variant
Selected variant
Specifications
| Connection | G1/4 female |
|---|---|
| Flow Max l/min Double | 4 |
| Function | Rotor |
| Material of connection | Nickel-plated brass |
| Material of glass tube | Borosilicate glass |
| Material of rotor | POM |
| Material of seals | NBR |
| Materials Wipers | NBR |
| Media | Water, oil |
| Min flow rate for rotor (oil 40 Cst) l/min | 1,5 |
| Min flow rate for rotor (oil 41-150 Cst) l/min | 2,7 |
|---|---|
| Min flow rate for rotor (water) l/min | 0,7 |
| Pressure drop | 0.25 bar at maximum flow |
| Pressure Range Max | 16 |
| Temperature range of media from | 0 |
| Temperature range of media to | 100 |
| Type of flow component | Flow indication |
| Weight | 0,35 |
| Viscosity Max | 150 |
Downloads
Product description
The WR1 mechanical flow indicator is designed for use with water, oils and air/gases to show a quantitative flow display though a spinning rotor.
